The DAHON HIT Folding Bike is a blend of functionality and style. Weighing only 11.54 kg, it's crafted for easy transportation and storage. Its folded size is a compact 65x34x82cm, making it perfect for urban environments. The frame is made from Dalloy Aluminum with a forged lattice hinge and ViseGrip technology, ensuring durability and strength.
The bike sports a high-tensile steel fork for stable and responsive handling. It comes with an adjustable DAHON V-bar forged aluminum stem, making it suitable for riders between 145-185cm in height and up to 137 kg in weight.
The drivetrain features a 52-tooth crankset with a double chain cover and a Loose Ball bottom bracket for smooth pedaling. The KMC Z6 chain and Shimano 6-speed 14-28T cassette ensure a reliable and varied gear range, while the Shimano TY21 rear derailleur provides crisp shifting.
Its 20" lightweight aluminum rims, stainless steel 14g spokes, and DAHON Custom 20"x1.75" tires offer excellent traction and durability. The bike is equipped with 110mm aluminum V-Brakes for effective stopping power.
Additional features include a DAHON Custom 74mm Compact Aluminum 20-hole front hub, a 28-hole aluminum rear hub, Shimano RS35 6-Speed Twist Shifter, a 6061 aluminum handlebar, DAHON Ergo Comfort grips, and a Fusion Zero Stack cartridge bearing headset. The bike also has DAHON 3-finger composite/aluminum brake levers, an Ergo Comfort saddle, and a custom 6061 aluminum seatpost. Lightweight aluminum kickstand and full aluminum fenders/rack complete the package.
Here are its standout features:
| Feature | Specification |
|---|---|
| Wheel Size | 20 inches |
| Weight | 11.54 kg |
| Folded Dimensions | 65x34x82cm |
| Frame | Dalloy Aluminum with lattice-forged hinge and ViseGrip technology |
| Fork | Stable and maneuverable Hi-Ten steel |
| Handlebar Stem | Adjustable V-bar in forged DAHON aluminum |
| Drivetrain - Crankset | 52-tooth with double chain guard |
| Drivetrain - Bottom Bracket | Loose Ball |
| Drivetrain - Chain | KMC Z6 |
| Drivetrain - Cassette | Shimano 14-28 teeth, 6-speed |
| Drivetrain - Rear Derailleur | Shimano TY21, 6-speed |
| Drivetrain - Pedals | Foldable DAHON, PC body and cage |
| Wheels - Rims | 20" lightweight aluminum |
| Wheels - Spokes | 14g stainless steel |
| Wheels - Tires | DAHON Custom 20" x 1.75" |
| Wheels - Brakes | Aluminum 110 mm V-Brakes |
| Rider Height Range | 145-185cm |
| Maximum Rider Weight | 137 kg |
| Additional Components - Front Hub | DAHON Custom 74mm Compact Aluminum, 20 holes |
| Additional Components - Rear Hub | Aluminum, 28 holes |
| Additional Components - Shifters | Shimano RS35, 6-Speed Twist |
| Additional Components - Handlebar | 6061 aluminum, 580 mm width |
| Additional Components - Grips | DAHON Ergo Comfort |
| Additional Components - Headset | Fusion, Zero Stack with cartridge bearings |
| Additional Components - Brake Levers | DAHON 3-finger, composite/aluminum |
| Additional Components - Saddle | DAHON Ergo Comfort |
| Additional Components - Seatpost | DAHON Custom 6061 aluminum, 33.9 mm x 580 mm |
| Additional Components - Kickstand | Lightweight aluminum |
| Additional Components - Rack and Full Fenders | Aluminum |
